DRIVE12AP

12″ two way active full range cabinet
24bit 48kHz digital speaker processor
4 Cabinet tone settings
3 band EQ
Adjustable limiter and delay
400 watts (RMS)
High quality durable injection moulded cabinet
Lightweight, high powered components
Product
Specification
Format
: 12″ two way active full range cabinet
Frequency response (-10dB)
: 50Hz 20kHz
Input sensitivity (Line)
: 0dBu
Input sensitivity (Mic)
: -40dBu
Max SPL
: 128dB
Amp Power
: 800W(PGM), 400W(RMS) / 350W(LF) + 50W(HF)
LF
: 12″ woofer / 50mm voice coil
HF
: 34mm compression driver / 1″ throat
Coverage (HxV)
: 80 x 40
Crossover
: 2.0kHz
Input Connection
: 2 x XLR/Jack combo + 1 x 3.5mm Jack
Power voltage
: 100V / 240V
Hanging system
: 5x M10 hanging points
Dimension W*H*D
: 390 x 630 x 360 (mm)
Weight
: 17KG
