2 x6 DSP Loudspeaker Management System for Pro Audio Excellence
Original price was: €1,250.00.€1,060.00Current price is: €1,060.00. (inc. VAT)
2 Input x 6 Output Digital Loudspeaker Management processor
Out of stock
The DLM 260 is an amazingly flexible tool for audio engineers and installation integrators. DSP based 2 input x 6 output Digital Loudspeaker management processor. It combines many functions of a multitude of conventional products in a compact 1U unit with extensive PC remote control capabilities.
· Hi-pass/Lo-pass/Shelving custom Q second order filters
· RMS compressor and PEAK limiter on each output channel with time constant and algorithm optimized for speaker thermal and mechanical protection while maximizing the output with no audible distortion
· Input channel L, R or L + R freely assignable to each output channel
·Double Compressor Limiter Mode (DCL) with two band RMS compressor and Peak limiter with adjustable HP / LP split frequency and separate parameter adj. This is an exclusive and very useful feature in general purpose digital processors
· ALL PASS first and second order filters useful for Cardioid SUB configurations, very precise phase crossover alignment, special pattern control array, alignment between different speakers and systems.
Each output has 4 fully configurable filters, a delay of 288.66ms max in step of 6.8us, gain, phase, LO-pass/Hi-pass crossover from 6 to 24db/Oct with standard or custom Q, RMS compressor with soft knee and peak limiter.
