4-in 8-out Audio Processor
Out of stock
Description
Designed for the highest sound quality, intuitive control and excellent performance. The XD-4080 professional matrix DSP system controller is the big brother of the XP series and the flagship of the family. With a powerful DSP, FIR filter brick wall and AES / EBU. By using up-to-date DSP electronics and hardware technologies, the XD series is positioned among the top players in the pro audio industry.
Features
- AES-EBU digital I/O using DB-25 multi-pin connector to suit larger digital deployments
- High performance FIR crossover filters
- Phase correction
- Dual IIR crossover per input /output
- Xconsole GUI software for MAC & PC or front panel control
- USB, RS232 and Ethernet connectivity
- 32 presets stored on device
- 24 bit AD/ DA conversion,40 bit floating point DSP,96 Khz sampling rate guarantees high end quality audio
- All inputs offer 650ms delay , 31 band graphic EQ, 8 parametric EQ’s , a complete filter section ( max 48dB) and a compressor
- All outputs offer 650 ms delay, 8 band parametric EQ’s, a complete filter section( max 48dB) And a true RMS limiter
- Works with ACX touch app
Specifications
- Input impedance – >10kΩ
- Output impedance – 50Ω
- Maximum level – +20dBu
- Frequency response – +/-0.1dB (20 to 30kHz)
- Dynamic range – 115dB
- Distortion – 0.002% (1kHz @ +4dBu)
- Sampling rate – 96kHz
- Analog converters – High-performance 24-bit
- Processor – 40-bit Floating point
- Power: 90-265 VAC (50/60Hz) – 20VA
- Dimensions: 19”x1.75”x9” (483x44x229mm)
- Weight: 10 lbs / 4.6 Kg
