ZOOM UAC-2
Original price was: €315.00.€195.00Current price is: €195.00. (inc. VAT)
Audio Interface 24-bit / 192kHz
2 Inputs / outputs Balanced XLR combo inputs and 6.3 mm jack
Out of stock
The bus-powered UAC-2 adds two channels of 24-bit/192 kHz high-resolution audio to any USB 2.0 or 3.0-equipped Windows or Mac computer—even to your iPad.* It utilizes SuperSpeed USB 3.0 technology for low latency and includes advanced features such as 4x upsampling, Loopback, and MIDI I/O. Plug in any microphone, line-level device, or instrument and use the UAC-2 for onstage playback, recording to a DAW, or enjoyment of high-res audio in your home or office.
·2-in/2-out SuperSpeed USB 3.0 audio interface
·Support for recording and playback up to 24-bit/192 kHz
·Loopback function for webcasting, podcasting, gaming, and other live streaming applications
·Low latency overdubbing and direct monitoring for zero-latency monitoring in mono or stereo
·Two combo balanced XLR/TRS input connectors accept both mic- and line-level signal
·Hi-Z switches allow direct connection of electric guitar or bass
·Switchable +48V phantom power
·Two balanced TRS output jacks for connection to amplifiers or self-powered speakers
·¼” headphone jack with dedicated level control
·Independent gain controls and clip LEDs for each input
·Large knob output volume control
·Direct Monitoring switch for zero latency monitoring in mono or stereo
·MIDI In and Out
·Compatible with all popular DAW and streaming software, including Cubase, Logic, Garage Band, Pro Tools, Ableton Live, and others
·High-performance mic preamps with up to +60dB of amplification
·120dB of dynamic range
·4x upsampling during A/D and D/A conversion for reduced noise and enhanced fidelity
·Asynchronous transfer system unaffected by computer jitter
·Bus powered—no AC power required
·Robust metal housing ensures roadworthiness
·Works with all USB 3.0-equipped computers and iPads*
* Optional power adapter and Apple Camera Connection kit or Lightning to USB Camera Adapter required
INPUTS
INPUT 1/2 CONNECTORS: XLR/TRS combo jacks (XLR: 2 hot / TRS: TIP hot)
INPUT GAIN: 0 to 60dB in 1dB steps
INPUT IMPEDANCE: 5kΩ (1 MΩ (when Hi-Z ON)
MAXIMUM INPUT LEVEL: +12 dBu (@0dBFs)
PHANTOM POWER: +48V
L/R OUTPUT
TYPE: ¼” TRS jack (Balanced)
MAXIMUM OUTPUT LEVEL: +14 dBu (@0dBFs)
OUTPUT IMPEDANCE: 100Ω
PHONES OUTPUT
TYPE: ¼” stereo phone jack 20mW + 20mW (into 32Ω load)
MAXIMUM OUTPUT LEVEL: +8 dBu (@0dBFs)
OUTPUT IMPEDANCE: 33Ω
DYNAMIC RANGE
A/D: 118dB typical (IHF-A)
D/A: 120dB typical (IHF-A)
NUMBER OF AUDIO CHANNELS
RECORDING: 2
PLAYBACK: 2
OTHER
FREQUENCY CHARACTERISTICS: -1.0 dB: 20 Hz – 60 kHz @ 192kHz -1.0 dB: 20 Hz – 40 kHz @ 96kHz -1.0 dB: 20 Hz – 20 kHz @ 44.1kHz
MEASURED CONVERSION NOISE (EIN): -125dBu (IHF-A) @ 60dB, 150Ω input
SAMPLING FREQUENCIES: 192kHz, 176.4kHz, 96kHz, 88.2kHz, 48kHz, 44.1kHz
BIT DEPTH: 24-bit
INTERFACE: USB 3.0
MIDI IN/OUT: 5-pin DIN jack
POWER SOURCE: USB 3.0 Bus Power / AD-14 AC adapter (DC 5V 1A)
POWER CONSUMPTION: 5 W maximum
DIMENSIONS: 113.9mm(D) x 176.0mm(W) x 46.2mm (H)
WEIGHT: 750g
UAC-2 SYSTEM REQUIREMENTS
WINDOWS: OS： Windows® 8 ~ 11 (32bit/64bit) CPU: Intel® Core i3 or faster* USB: USB 3.0/USB 2.0** * Operation is not guaranteed with CPUs from Atom, Celeron or Pentium series or CPUs made by AMD. ** Only USB host controllers with Intel Chipsets are supported. Operation is not guaranteed when used with USB hubs or expansion cards.
MAC: OS： macOS 10.14 ~ 12 CPU: Intel® Core i3 or fasterUSB: USB 3.0/USB 2.0** Operation is not guaranteed when used with USB hubs or expansion cards.
IPHONE/IPAD: OS: iOS 7.1 ~ 15 * Optional power adapter(AD-14) and Apple Camera Connection kit or Lightning to USB Camera Adapter required.
