Quadro DSP
Original price was: €1,050.00.€890.00Current price is: €890.00. (inc. VAT)
Professional speaker processor, with variable DSP functions, and integrated compressors, limiters, frequency dividers, dynamic EQ, delayers, equalizers, input and output with FIR phase correction, and audio mixers.
Suitable for stadium, performances, auditoriums, halls, and conference rooms.
Only 1 left in stock
Digital speaker management system, 4 input, 8 outputs full matrix mixing, 32 bit converters with 96khz sampling, USB Connection for PC or RJ45 LAN Connector for Long Distance Control, ? programmable PC Software, Low-Shelving Equalizer, Hi-Shelving Equalizer, Lo-Cut filter, Hi-Cut filter, All-Pass filter, Compressor / Limiter 6 Digital Compressors / Limiters per Output, state-of-the-art signal processing.
DSPMODULE
- Signal processing: ADI SHARC 21489
- Audio system delay: 2.8 ms
- D/A conversion: 24-bit
- Sampling Rate: 96kHz
ANALOG AUDIO INPUTS AND OUTPUTS
- Input channel: 4 balanced inputs.Line level.
- Audio interface: Cannon male and female
- Input resistance: 22kΩ
- Maximum input level: 16dBu/Line
- Output channel: 8x balanced outputs, Line level
- Output impedance: 150Ω
AUDIO PERFORMANCE SPECIFICATIONS
- Frequency response curve: 20Hz～40kHz(±0.5dB)/Line
- Noise floor: 20Hz～20kHz,A-wt,-93dBu
- THD+N: -90dB(@0dBu,1kHz,A-wt)/Line
- SNR: 108dB(@16dBu,1kHz,A-wt)/Line
COMMUNICATION PORTS AND INDICATORS
- USB: Micro-B type
- Serial port
- RJ-45, for TCP/IP network connection
- LED Indicators: CLIP, LEVEL, EDIT, MUTE
