ZOOM F1-LP
Original price was: €220.00.€185.00Current price is: €185.00. (inc. VAT)
Field Recorder and Lavalier Microphone Set
Out of stock
The Zoom F1 Field Recorder + Lavalier Mic is the perfect solution for videographers who need to capture the nuance of every word with professional quality audio.
· Two-channel audio recorder
· Compatible with Zoom microphone capsules
· Supports up to 24-bit/96 kHz audio in BWF-compliant WAV or a variety of MP3 formats
· One-touch button controls
· 1.25” monochrome LCD display
· Rec Hold function to avoid accidental operation of buttons
· Stereo ⅛" Mic/Line In mini phone jack with Plug-in power (2.5V)
· Stereo ⅛" Phone/Line Output jack with dedicated volume control
· Built in limiter and auto level control to avoid clipping
· Pre-Record function
· Tone generator for calibrating audio levels between the F1 and a DSLR or video camera without the need for an attenuator cable
· Sound marker function that outputs quick tone to make syncing audio and video easy
· Records directly to micro SD and SDHC cards up to 32 GB
· Micro USB port for data exchange to and from computer and use as an audio interface with computer or iOS device
· Runs on only 2 standard AAA alkaline, Lithium, or NiMH rechargeable batteries, or AC adapter (AD-17)
· Up to 10 hours of operation with alkaline batteries (when using lavalier)
*Camera not included
RECORDING MEDIA: microSD/microSDHC cards
(Class 4 or higher, up to 32 GB)
RECORDING FORMATS: WAV
44.1 kHz/16-bit, 48 kHz/16-bit, 48 kHz/24-bit, 96 kHz/24-bit
MP3
48 kbps, 128 kbps, 192 kbps, 256 kbps, 320 kbps
Mono/stereo ID3v1 tags supported
DISPLAY: 1.25" monochrome LCD
INPUTS
MIC IN : ZOOM mic capsule input
MIC/LINE IN: Connector: 3.5 mm stereo mini (with screw lock)
Supports plug-in power (2.5 V)
Input gain: −12 dB – +36 dB
Input impedance: 2 kΩ or more
LAVALIER MIC : Plug: 3.5 mm stereo mini (with screw lock)
Directionality: Omnidirectional
Sensitivity: -32 dB/1 Pa at 1kHz
Maximum sound pressure input: 115 dB spl
Cable length: 160 cm
OUTPUTS
PHONE OUT : Connector: 3.5 mm stereo mini (with screw lock)
Maximum output level: 11 mW + 11 mW (into 32 Ω load)
USB: microUSB
Mass storage operation: USB 2.0 High Speed
Audio interface operation: USB class compliant
44.1kHz/16-bit, 48kHz/16-bit, 2-in/2-out
Transfer method: asynchronous
POWER
2 AAA batteries (alkaline, NiMH or lithium)
AC adapter (ZOOM AD-17): DC 5V/1A
RECORDING TIME USING BATTERIES: Lavalier mic (48 kHz/24-bit, mono, plug-in power on):
Alkaline batteries: about 10 hours
NiMH batteries 750 mAh): about 9 hours
Lithium batteries: about 16 hours
*The above values are approximate.
DIMENSIONS: 64 mm (W) x 79.8 mm (D) x 33.3 mm (H)
WEIGHT: 120 g (without batteries)
