Professional 12-Channel USB Mixer for Ultimate Sound Mastery
Original price was: €575.00.€515.00Current price is: €515.00. (inc. VAT)
12-Channel Mixer with USB Player
Only 1 left in stock
AMX 1624 USB Mixers
| Weight | 6.4 kg |
|---|---|
| Dimensions | 500 × 360 × 100 cm |
·8 mono channels + 4 stereo mixer
·MIC/LINE mono channels with +48V phantom supply
·3 bands equalizaer in every channel
·Send buses and effect control
·24 bits DSP built-in with 24 different effects
·USB/SD interface for MP3 files
·Balanced/Unbalanced master outputs with separate faders
·7 bands graphic equalizer in Master section
·Footswitch connection (effects mute) and headphones
Description: 8 MIC/LINE mono channels + 4 stereo mixer.
Noise (20Hz-20kHz) 150ohm (all outputs, master level & all channels off): -95 dB.
Input noise (Max. gain):-125 dBu.
Residual current (off levels):-95 dBu.
(Unit Master, off channels):-80 dBu.
(Unit Master, unit channels):-80 dBu.
THD+N:<0,5% @ 4 dBu de salida.
Frequency response:20 Hz – 30 kHz (0 dB / – 3 dB).
Crosstalk (adjacent inputs):- 90 dB @ 1 kHz.
Crosstalk (inputs / outputs):- 90 dB @ 1 kHz.
Crosstalk (faders off):- 75 dB @ 1 kHz.
Maximum level (inputs):+22 dBu.
Maximum level (mix):+28 dBu.
Low cut:100 Hz / – 12 dB per octave.
EQ high:+- 15 dB @ 12 kHz.
EQ middle:+- 15 dB @ 2,5 kHz.
EQ bass:+- 15 dB @ 80 Hz.
Main supply:240 V AC, 50 Hz.
·Description: 8 MIC/LINE mono channels + 4 stereo mixer
·Noise (20Hz-20kHz) 150ohm (all outputs, master level & all channels off): -95 dB
·Input noise (Max. gain):-125 dBu
·Residual current (off levels):-95 dBu
·(Unit Master, off channels):-80 dBu
·(Unit Master, unit channels):-80 dBu
·THD+N:<0,5% @ 4 dBu de salida
·Frequency response:20 Hz – 30 kHz (0 dB / – 3 dB)
·Crosstalk (adjacent inputs):- 90 dB @ 1 kHz
·Crosstalk (inputs / outputs):- 90 dB @ 1 kHz
·Crosstalk (faders off):- 75 dB @ 1 kHz
·Maximum level (inputs):+22 dBu
·Maximum level (mix):+28 dBu
·Low cut:100 Hz / – 12 dB per octave
·EQ high:+- 15 dB @ 12 kHz
·EQ middle:+- 15 dB @ 2,5 kHz
·EQ bass:+- 15 dB @ 80 Hz
·Main supply:240 V AC, 50 Hz
·Dimensions:500 x 360 x 100 mm
·Weight:6.4 kg
