8-Channel USB Mixer with FX Control & EQ Features
Original price was: €495.00.€445.00Current price is: €445.00. (inc. VAT)
8-Channel Mixer with USB Player
Only 1 left in stock
The AMX series consists of two mixers with 4 and 8 mono MIC/LINE channels and 4 additional stereo channels. Each mono channel incorporates a +48V phantom-powered preamp for condenser microphones and a 100 Hz low cut filter.
All mono and stereo channels feature 3-band EQ and individual Monitor and FX send bus controls along with PAN and BAL control according to channel type.
The Master section includes separate master outputs, monitor bus control and stereo and FX returns.
| Weight | 6.1 kg |
|---|---|
| Dimensions | 400 × 360 × 100 cm |
·4 mono channels + 4 stereo mixer.
·MIC/LINE mono channels with +48V phantom supply.
·3 bands equalizaer in every channel.
·Send buses and effect control.
·24 bits DSP built-in with 24 different effects.
·USB/SD interface for MP3 files.
·Balanced/Unbalanced master outputs with separate faders.7 bands graphic equalizer in Master section.Footswitch connection (effects mute) and headphones.
Description: 4 MIC/LINE mono channels + 4 stereo mixer.
Noise (20Hz-20kHz) 150 ohm (all outputs, master level & all channels off): -95 dB
·Input noise (Max. gain): -125 dBu
·Residual current (off levels): -95 dBu
·(Unit Master, off channels): -80 dBu
·(Unit Master, unit channels): -80 dBu
·THD+N: <0,5% @ 4 dBu de salida
·Frequency response: 20 Hz – 30 kHz (0 dB / – 3 dB)
·Crosstalk (adjacent inputs): – 90 dB @ 1 kHz
·Crosstalk (inputs / outputs): – 90 dB @ 1 kHz
·Crosstalk (faders off): – 75 dB @ 1 kHz
·Maximum level (inputs): +22 dBu
·Maximum level (mix): +28 dBu
·Low cut: 100 Hz / – 12 dB per octave
·EQ high: +- 15 dB @ 12 kHz
·EQ middle: +- 15 dB @ 2,5 kHz
·EQ bass: +- 15 dB @ 80 Hz
·Main supply: 240 V AC, 50 Hz
